Phoenix DC-DC Inverter 12/3000 120V

The Phoenix 12/3000 is a compact, high-power inverter for mobile and off-grid applications: campers, boats, and stand-alone installations. It combines very good efficiency, high starting capacity, and flexible integration (VE.Bus), providing stable power to demanding 120 VAC loads.

Key Features

HF/LF Hybrid Technology

Combining the advantages of high (HF) and low frequency (LF) ensures high starting power in a compact size and weight. Ideal for devices with high starting currents in campers, boats, and off-grid systems.

3000 VA continuous power, up to 6000 W peak

High reserve power enables trouble-free start-up of demanding loads. Efficiency of over 94% minimizes losses and extends battery runtime.

Flexible Integration

Support for parallel and three-phase/split-phase operation allows for system scalability. Communication via VE.Bus simplifies configuration and integration with the Victron platform (e.g., Cerbo GX, VRM).

Professional Design

The SinusMax series delivers pure sine wave output and optimized efficiency without compromising power quality.

Automatic Transfer Switch

The built-in switch (and a charger with the option to turn it off) ensures very fast switching, ensuring that sensitive electronics (e.g., computers) operate without interruption.

Interface and Monitoring

The VE.Bus port (e.g., via MK3-USB) and integration with GX devices enable remote viewing and control of the system via the VRM portal.

Scalability for Large Installations

The use of multiple 12/3000 inverters enables the construction of installations with a capacity of several dozen kW in parallel, three-phase, or split-phase configurations, including in renewable energy systems.

Technical Specifications

Electrical Parameters

Input Voltage Range (VDC) 9.5–17 V
Output Voltage 120 VAC ± 2%
Frequency 60 Hz ± 0.1%
Parallel / 3-Phase / Split-Phase Yes

Power Efficiency

Continuous Power at 25°C (VA) 3000
Continuous Power at 25°C (W) 2400
Continuous Power at 40°C (W) 2200
Continuous Power at 65°C (W) 1700
Peak Power (W) 6000
Peak Efficiency 93%

Power Consumption and Modes

No-Load Power Consumption 20 W
Power Consumption in Off-Load Mode AES 15 W
Power consumption in Search mode 8 W

Functions and interface

Programmable relay Yes
Protections a) output short circuit; b) overload; c) too high battery voltage; d) too low battery voltage; e) too high temperature; f) presence of 120 VAC at the inverter output; g) excessive input voltage ripple.
VE.Bus communication port For parallel and 3-phase operation, remote monitoring, and system integration.
Remote on/off Yes.

Operating conditions

Operating temperature -40 to +65 °C.
Humidity Max. 95% (non-condensing).

Mechanics and connections.

Housing material and color. Aluminum, RAL blue. 5012
Housing Protection Class IP21
Battery Connection (DC) 2+2 M8 Screws
AC Connection 120 V Screw Terminals
Weight 18 kg
Dimensions (H × W × D) 362 × 258 × 218 mm

Standards

Safety EN 60335-1
Emission / Immunity EN 55014-1 / EN 55014-2
