Residual Current Circuit Breaker - 1P+N - 25A 300mA - AC type - 2 modules - Hager CFC225P

Residual current circuit breaker (RCCB) with 2 poles (1P+N), AC protection type, 300mA sensitivity, and a rated current of 25A, designed for installation in distribution boards. It operates at 50Hz and supports working voltages of 127/230V, providing protection against earth leakage currents in power supply circuits. The switching mechanism uses 2 modules, with connection terminals for 16mm² flexible cable and 25mm² rigid cable. It guarantees operation between -5°C and 40°C, ensuring reliability and safety in both domestic and industrial installations.

Specifications:

• Number of poles: 2

• Type of residual protection: AC

• Residual sensitivity: 300mA

• Rated current: 25A

• Operating frequency: 50Hz

• Rated AC operating voltage: 127/230V

• Number of modules: 2

• Flexible cable connection size: 16mm²

• Rigid cable connection size: 25mm²

• Operating temperature: -5 to 40°C
